Alarms and events
286
A
Invalid Setting GF From CPUA
Change Rejected
Messenger has received an invalid ground fault
enable or disable setting from CPU A and has
rejected the value
This event is recorded by CPU B based on
status information sent to the Messenger by
CPU A. The Sequence of Events for CPU A
should have an “Invalid Setting GF Change
Rejected” or “Invalid Setting GF Pickup
Change Rejected” event. See the description
of those events for details.
Invalid Setting GF From CPUB
Change Rejected
Messenger has received an invalid ground fault
enable or disable setting from CPU B and has
rejected the value
This event is recorded by CPU A based on
status information sent to the Messenger by
CPU B. The Sequence of Events for CPU B
should have an “Invalid Setting GF Change
Rejected” or “Invalid Setting GF Pickup
Change Rejected” event. See the description
of those events for details.
Note Messngr Ignored Invalid
Command CPUA
Messenger has received an invalid command from
CPU A and will ignore it
Contact GE Post Sales Service (see
Note Messngr Ignored Invalid
Command CPUB
Messenger has received an invalid command from
CPU B and will ignore it
Contact GE Post Sales Service (see
Note Messngr Arbitrated
Command From CPUA
Messenger has received conflicting commands
from CPU A
Examine event logs from both CPUs to
determine if CPUs sent conflicting
commands at approximately the same time.
Note Messngr Arbitrated
Command From CPUB
Messenger has received conflicting commands
from CPU B
Examine event logs from both CPUs to
determine if CPUs sent conflicting
commands at approximately the same time.
Note Messngr Reports CPUA
Command Timed Out
Command sent to Messenger from CPU A has
timed out
•
Verify that breaker is in the Test or
Connect position.
•
If Open command timed out, check shunt
trip fuse.
•
If Close command timed out, verify that
breaker is an electric breaker. If it is, verify
that closing spring is charged, also check
the fuse for the charging motor.
•
Contact GE Post Sales Service (see
).
Note Messngr Reports CPUB
Command Timed Out
Command sent to Messenger from CPU B has
timed out
Same as CPU A above.
CPUA Synch Clock OK
Messenger reports that CPU A is using the CPU
Synch Clock (event recorded by CPU B)
CPUB Synch Clock OK
Messenger reports that CPU B is using the CPU
Synch Clock (event recorded by CPU A)
Caution CPUA Synch Clock Err
Backup Clock On
Messenger reports that CPU A is not using the CPU
Synch Clock (event recorded by CPU B)
Verify that CPU A is connected to the CPU
Synch Clock, verify that the CPU Synch Clock
is operating correctly.
Table A-10 Messenger/Breaker Config Status Events
Event
Description
Notes and Troubleshooting tips
