Alarms and events 270
A
A.2.6 Breaker Command and Control Events
A.2.7 Breaker Status Events
Table A-7 Breaker Command and Control Events
Event Description Notes and Troubleshooting tips
Breaker Close Command
Issued from HMI For [Breaker
Name] Logged when an operator issues a close command
for a given breaker
Breaker Open Command
Issued from HMI For [Breaker
Name] Logged when an operator issues an open
command for the specified breaker
Breaker Trip Command Issued
from HMI For [Breaker Name] Logged when an operator issues a trip command
for the specified breaker
[Alarm Name] Is In Alarm
Condition The specified alarm has entered the active
condition.
Attention: Control Power 1
Outage Detected On Battery
Backup The primary control power source has experienced
an outage and is now operating from the UPS
battery backup.
Attention: Control Power 1 Low
Battery Detected Shutdown in
2 mins The HMI will shutdown in the specified amount of
time due to impending outage of the UPS battery
backup.
Control Power 1 Power
Restored Power has been restored to the primary control
power bus.
Requested
Multipoint RELT Logged by HMI when user initiates RELT
Requested To End
Multipoint RELT Logged by HMI when user turns off RELT
Table A-8 Breaker Status Events
Event Description Notes and Troubleshooting tips
Attention Breaker Open Failed
Shunt Trip CPU sent an open with shunt trip command to
Messenger, but data sent by Messenger indicates
that breaker did not open • Verify that breaker is in the Test or
Connect position.
• Check shunt trip fuse.
•
Contact GE Post Sales Service (see How
to contact us on page 2 ).
