A.2.2 Commands from HMI
User With [USER ID] ID Logged
Into HMI
Indicates that the specified operator has logged
into the HMI application
User With [USER ID] ID Logged
Off HMI
Indicates that the specified operator has logged
out of the HMI application
Caution: Unable to Read HMI
Config File(elvs_config.bcf).
Defaults Loaded
The HMI was unable to load the local configuration
file from disk.
Contact GE Post Sales Service (see
).
HMI Config File Loaded OK
The HMI successfully loaded the local
configuration file from disk.
Caution: Error Saving HMI
Config File
The HMI was unable to successfully store the local
configuration file to disk.
Contact GE Post Sales Service (see
).
HMI Config File Saved OK
The HMI successfully loaded the local
configuration file from disk.
Switched to Entellisys LV
Lineup
Logged on switching to another lineup
HMI is restarted for Periodic
maintenance
The HMI has restarted itself as part of its periodic
self-maintenance routine.
Table A-2 HMI Internal Operations
Event
Description
Notes and Troubleshooting tips
Table A-3 Commands from HMI
Event
Description
Notes and Troubleshooting tips
CPU Reinitialized Issued
CPU is going to reboot, either because of a Modbus
command, or an internal issue.
The reason for the CPU reboot should be in
the event log. It will be one of the following:
CPU Reinitialize By Command, Note CPU
Internal Error 1, Note CPU Internal Error 2,
Note CPU Internal Error 3
CPU Reinitialize By Command
CPU rebooted by Modbus reset relay command
The reset relay command is issued after new
firmware or a new option string is
downloaded to the CPU.
Breaker Open Command
Received
CPU received a command via Modbus to open a
breaker
Breaker Close Command
Received
CPU received a command via Modbus to close a
breaker
Breaker Trip Command
Received
CPU received a command via Modbus to trip a
breaker
Events Cleared By Command
CPU received (via Modbus) and executed a
command to clear its event log
