Alarms and events 272
A
A.2.8 Protection Relay Events
Attention IO Card Detection
Mismatch Found 0 of 2 CPU expected 2 discrete I/O cards, but detected
none Contact GE Post Sales Service (see How to
contact us on page 2 ).
Attention IO Card Detection
Mismatch Found 1 of 0 CPU expected no discrete I/O cards, but detected 1 Contact GE Post Sales Service (see How to
contact us on page 2 ).
Attention IO Card Detection
Mismatch Found 1 of 2 CPU expected 2 discrete I/O cards, but detected 1 Contact GE Post Sales Service (see How to
contact us on page 2 ).
Attention IO Card Detection
Mismatch Found 2 of 0 CPU expected no discrete I/O cards, but detected 2 Contact GE Post Sales Service (see How to
contact us on page 2 ).
Attention IO Card Detection
Mismatch Found 2 of 1 CPU expected 1 discrete I/O card, but detected 2 Contact GE Post Sales Service (see How to
contact us on page 2 ).
Table A-8 Breaker Status Events
Event Description Notes and Troubleshooting tips
Table A-9 Protection Relay Events
Event Description Notes and Troubleshooting tips
Alarm Pickup Undervoltage Alarm only undervoltage relay has entered pickup
Alarm Undervoltage Alarm only undervoltage relay has operated
Alarm Dropout Undervoltage Alarm only undervoltage relay has dropped out of
pickup
Voltage Below Undervoltage
Alarm Blocking Voltage The voltages on all three phases have dropped
below the alarm only undervoltage blocking
voltage threshold.
Voltage Above Undervoltage
Alarm Blocking Voltage The voltage on at least one of the three phases has
exceeded the alarm only undervoltage blocking
voltage threshold.
Pickup Undervoltage Undervoltage relay has entered pickup
Breaker Trip Undervoltage Undervoltage relay has operated
Dropout Undervoltage Undervoltage relay has dropped out of pickup
Voltage Below Undervoltage
Blocking Voltage The voltages on all three phases have dropped
below the undervoltage blocking voltage threshold.
Voltage Above Undervoltage
Blocking Voltage The voltage on at least one of the three phases has
exceeded the undervoltage blocking voltage
threshold.
Alarm Pickup Overvoltage Alarm only overvoltage relay has entered pickup
Alarm Overvoltage Alarm only overvoltage relay has operated
