Alarms and events
280
A
HRGF Location - Detection Not
Optioned Function 1-4
Logged when breaker that location function 1 is
associated with does not have HRGF optioned.
HRGF Location Incomplete
Missing Data Function 1-4
This event is logged when some messengers are
either decommissioned or non-communicating or
not-synched.
Relays – Synch Check
Synch Check Control Enabled
1…12
Synch check relay 1…12 has been enabled
Synch Check Control Disabled
1…12
Synch check relay 1…12 has been disabled
Synch Check 1…12 Sources Not
Synchronized
Messengers that are providing voltage information
for synch check relay are not synchronized, so the
CPU is unable to check for synchronization
between voltage sources.
This should only happen on start-up, or when
a Messenger is connected to the system (or
rebooted). If it happens repeatedly during
normal operation, contact GE Post Sales
Service (see
Synch Check 1…12 Sources Not
Compatible
Voltage sources for synch check relay 1…12 are not
compatible; i.e., they have different PT
configurations or ratings
•
Verify that the Source Voltages for the
synch check relay are correct.
•
Verify that the source voltages have the
correct PT configurations.
Synch Check 1…12 Dead Source
Operate
Dead source criteria for synch check relay 1…12
have been met
Synch Check 1…12 Dead Source
Drop Out
Dead source criteria for synch check relay 1…12
have been met
Synch Check 1…12 V1 Above
Minimum
Voltage source 1 for synch check relay 1…12 is
above the live source threshold
Synch Check 1…12 V1 Below
Maximum
Voltage source 1 for synch check relay 1…12 is
below the dead source threshold
Synch Check 1…12 V2 Above
Minimum
Voltage source 2 for synch check relay 1…12 is
above the live source threshold
Synch Check 1…12 V2 Below
Maximum
Voltage source 2 for synch check relay 1…12 is
below the dead source threshold
Overcurrent (including GF)
Pickup ST Overcurrent
Short time overcurrent function has entered pickup
Dropout ST Overcurrent
Short time overcurrent function has dropped out of
pickup
Breaker Trip ST Overcurrent
Breaker tripped due to short time overcurrent
condition
Pickup LT Overcurrent
Long time overcurrent function has entered pickup
Table A-9 Protection Relay Events
Event
Description
Notes and Troubleshooting tips
