Alarms and events description and system troubleshooting guide
265
A
Caution: CPUA and CPUB have
duplicate IDs
Both CPUs are given the same designation (A and
or B).
Contact GE Post Sales Service immediately
(see
). Certain
control schemes and advanced features of
Entellisys will not function in this state.
Caution: Invalid ID for CPUA.
Expecting ID 0
The designation in the CPU firmware does not
match the designation assigned to that CPU in the
HMI.
Verify that the IP addresses for each CPU are
not reversed with respect to their A and B
designations.
Caution: Invalid ID for CPUB.
Expecting ID 1
The designation in the CPU firmware does not
match the designation assigned to that CPU in the
HMI.
Verify that the IP addresses for each CPU are
not reversed with respect to their A and B
designations.
Attn:Settings Discrepancy btwn
CPUA & CPUB. Updt in
Maintenance-Settings Menu
The settings are not consistent between the
primary and redundant CPUs and require
synchronization.
Open the Settings File tab under the
Maintenance dialog box to synchronize the
settings files. Note that a sufficient privilege
level is required to perform this action.
Caution: Option Mismatch
between CPUA and CPUB. Retry
The available options programming is not
consistent between the primary and redundant
CPUs.
Contact GE Post Sales Service (see
Attention: CPU Firmware Version
Mismatch between CPUA and
CPUB
The firmware revisions are not consistent between
the primary and redundant CPUs.
Check the CPU Firmware tab under the
maintenance menu, or contact GE Post Sales
Service (see
Note that a sufficient privilege level is
required to perform this operation.
CPUA Commissioned
CPU A transitioned from the decommissioned state
to the commissioned state.
CPUB Commissioned
CPU B transitioned from the decommissioned state
to the commissioned state.
CPUA Decommissioned
CPU A transitioned from the commissioned state to
the decommissioned state.
Contact GE Post Sales Service if this occurs
when not expected (see
).
CPUB Decommissioned
CPU B transitioned from the commissioned state to
the decommissioned state.
Contact GE Post Sales Service if this occurs
when not expected (see
).
Table A-5 CPU Settings Related Events
Event
Description
Notes and Troubleshooting tips
