Discrete I/O
188
10
File Parse Failure
Invalid “File name”/“IED name”/“AccessPoint
name” or Publisher cid/icd file format not
supported by Entellisys.
1.Check HMI GOOSE I/O screen “FILENAME”,
“IEDNAME”, “ACCESS PT” fields and reapply
GOOSE Input setting.
2.Verify publisher “APPID” is in range: 0 to
0xFFFF.
3.Verify publisher “orCat”
need to modify publisher cid/icd file directly.
4.Verify “DataSet” is available and valid at
publisher and its cid/icd file. Entellisys only
supports GGIO data item (set) and Boolean
data type.
Data Type/Item Creation Failure
Data type/Item not supported by Entellisys.
Entellisys only supports GGIO data item and
Boolean data type.
Check GOOSE configuration on the
publisher device.
MAC Address Initialization Failure
Destination MAC Address
Mismatch
Invalid or incorrect publisher destination MAC
address.
Check GOOSE configuration on the
publisher device and use Entellisys HMI to
load new publisher cid/icd files to Entellisys
subscriber components.
VLAN Priority Parse Failure
VLAN ID Parse Failure
Publisher cid/icd file contains invalid VLAN
priority / VLAN ID.
Check GOOSE configuration on the
publisher device.
All other error code
Entellisys internal error.
Record error code and contact GE support.
Table 10-2 GOOSE Input troubleshooting
Message
Explanation
Solution
