Alarms and events description and system troubleshooting guide 267
A
Attention Messngr
Decommssned Msg Proto Ver Message protocol version sent by Messenger does
not match what is expected, Messenger
decommissioned Messenger and CPU are incompatible,
contact GE Post Sales Service (see
How to
contact us on page 2 ).
Attention Messngr
Decommssned Dupe IDs Seqs Two Messengers with the same ID have been
detected Contact GE Post Sales Service (see How to
contact us on page 2 ).
Attention Messngr
Decommssned Dupe Ids Two Messengers with the same ID have been
detected Contact GE Post Sales Service (see How to
contact us on page 2 ).
Adv Protection Default To Bus
Cfg 1 Brkr Err Topology breaker is in an undefined state (i.e. not
open and not closed), therefore system topology
cannot be determined and CPU has defaulted to
bus configuration 1 Breaker service issue, contact GE Post Sales
Service (see
How to contact us on page 2 ).
Breaker Topology State Change Breaker topology has changed
Multipoint Relays Topology
State Change Logged when system topology changes
Adv Protection Default To Bus
Cfg 1 File Err Configuration files that define the system topology
states is bad or missing, and the CPU has defaulted
to bus configuration 1 Contact GE Post Sales Service (see How to
contact us on page 2 ).
Discrete IO Disabled Invalid Cfg
Card 1 CPU is unable to configure I/O for Card 1 Contact GE Post Sales Service (see How to
contact us on page 2 ).
Discrete IO Disabled Invalid Cfg
Card 2 CPU is unable to configure I/O for Card 2 Contact GE Post Sales Service (see How to
contact us on page 2 ).
Discrete IO Disabled Card In
Wrong Slot Only one I/O card detected, and it is plugged into
PMC1 instead of PMC0 Contact GE Post Sales Service (see How to
contact us on page 2 ).
Caution System Topology
Defaulted The system has reverted to the default topology
(topology 1). This occurs when the CPU is unable to
determine the state of one or more of the topology
breakers. Breaker service issue, contact GE Post Sales
Service (see
How to contact us on page 2 ).
Attentn PT Sources Defaulted
Invalid Cfg File The file that describes the PT sources for each
breaker for each topology is invalid. Each breaker is
now using its own voltage information, if any (this is
the default state). Contact GE Post Sales Service (see How to
contact us on page 2 ).
PT Throwover Has Occurred Something has caused the system topology to
change (typically a topology breaker has opened or
closed), and the PT sources for some breakers may
have changed.
Messngr Decommissioned
Manual Command Messenger was decommissioned by a command
received over Modbus
Messngr Commissioned Manual
Command Messenger was commissioned
ZSI Zone 1…4 Operation ZSI has udpated the delay times for functions in
zone 1…4
Table A-6 CPU Status Events
Event Description Notes and Troubleshooting tips
