Alarms and events 284
A
A.2.9 Messenger/Breaker Config Status Events
Alarm Pickup Under-Demand
Flex XX Under-Demand Flex Relay has entered pickup
Alarm Dropout Under-Demand
Flex XX Under-Demand Flex Relay has dropped out of
pickup
Alarm Under-Demand Flex XX Under Demand Alarm Relay has operated
Table A-9 Protection Relay Events
Event Description Notes and Troubleshooting tips
Table A-10 Messenger/Breaker Config Status Events
Event Description Notes and Troubleshooting tips
Caution Flux Shifter Failure
Reported Messenger’s Flux Shifter Circuit monitor has
malfunctioned.
•
Messenger should be replaced
immediately.
Caution Messngr Control Power
1 Lost Messenger reports that it has lost control power
source 1
•
Check LINE LED on UPS. If it is off, check
the main power switch on the UPS. If it is
off, turn it on. Otherwise, check the
control power fuse between the
transformer and the UPS.
•
If the LINE LED is on, check the ON LINE
LED. If it is off, see the UPS manual.
•
Check UPS fuse.
• Contact GE Post Sales Service (see How
to contact us on page 2 ).
Caution Messngr Control Power
2 Lost Messenger reports that it has lost control power
source 2 Same as control power 1 lost
Messngr Control Power 1 OK Messenger reports that control power source 1 is
present
Messngr Control Power 2 OK Messenger reports that control power source 2 is
present
Note Invalid Breaker Type Messenger reports a breaker type other than ANSI Compartment ID button has been
misconfigured, contact GE Post Sales Service
(see
How to contact us on page 2 ).
Protection Defaulted Invalid
Frame Rating Messenger reports a frame rating value that is not
valid, protection settings set to values that are safe
for all frame sizes Compartment ID button has been
misconfigured, contact GE Post Sales Service
(see
How to contact us on page 2 ).
Protection Defaulted Invalid CT
Rating Messenger reports a CT rating value that is not
valid, protection settings set to values that are safe
for all frame sizes Compartment ID button has been
misconfigured, contact GE Post Sales Service
(see
How to contact us on page 2 ).
Protection Defaulted Frame And
CT Mismatch Messenger reports frame and CT ratings that are
inconsistent, protection settings set to values that
are safe for all frame sizes Compartment ID button has been
misconfigured, contact GE Post Sales Service
(see
How to contact us on page 2 ).
