Alarms and events description and system troubleshooting guide
283
A
RELT Mode Multipoint - ON / OFF
request from User
Logged when a user enables or disables Multi-point
RELT from the HMI
See section
RELT Mode - ON / OFF request
from User
Logged when a user enables or disables
Single-point RELT from the HMI
See section
RELT Mode System Wide - ON /
OFF request from User
Logged when a user enables or disables System
Wide RELT from the HMI
RELT Mode System Wide - ON /
OFF request from FlexLogic
Logged when FlexLogic enables or disables System
Wide RELT
RELT Mode Multipoint - OFF
request from Modbus Dvc
Logged when a Modbus device initiates Multi-point
RELT mode
RELT Mode System Wide - ON
request from Modbus Dvc
Logged when a Modbus device initiates System
Wide RELT mode
Attention: RELT lock limit
reached - Modbus Device
Logged if more than 8 Modbus devices attempt to
enable RELT for an individual breaker
Attention: RELT Multipt lock limit
reached-Modbus
Logged if more than 8 Modbus devices attempt to
enable Multi-point RELT
Attention: RELT Sys Wide lock
limit reached-Modbus
Logged if more than 8 Modbus devices attempt to
enable System Wide RELT
Attention: RELT failed to initiate -
iButn cfg err
RELT failed due to an IButton error
Attention: RELT failed to initiate -
Comm Loss
RELT failed due to a comm loss
Attention: RELT failed to initiate -
LT Pickup
RELT failed because one of the breakers was in
Long Time Pickup
Attn: RELT MPt failed to
initiate-missing options
Multi-point RELT failed because none of the
Multi-point relays are optioned
RELT Mode Multipoint - ON / OFF
Request From FlexLogic
Logged when FlexLogic enables / disables
multipoint RELT
RELT Mode - ON / OFF Request
From FlexLogic
Logged when FlexLogic enables / disables RELT on
an individual breaker
Over and Under Demand Alarm
Alarm Pickup Over-Demand Flex
XX
Over-Demand Flex Relay has entered pickup
Alarm Dropout Over-Demand
Flex XX
Over-Demand Flex Relay has dropped out of pickup
Alarm Over-Demand Flex XX
Over-Demand Alarm Relay has operated
Table A-9 Protection Relay Events
Event
Description
Notes and Troubleshooting tips
