93
4 6C08 Zone X Summation MSGF Trip Delay Band
Setting (16 items) 0 to 6 --- 1 F713 2
6C18 Zone X Summation MSGF Alarm Delay Band
Setting (16 items) 0 to 6 --- 1 F713 2
6C28 Zone X Summation MSGF Trip I2T (16 items) 0 to 1 --- 1 F725 0
6C38 Zone X Summation MSGF Alarm I2T Curve
(16 items) 0 to 1 --- 1 F725 0
6C48 Zone X Summation MSGF Trip Enabled (16
items) 0 to 1 --- 1 F102 0
6C58 Zone X Summation MSGF Alarm Enabled (16
items) 0 to 1 --- 1 F102 0
6C68 Zone X Summation MSGF Trip Pickup Setting
(16 items) 30 to 1200 --- 10 F001 1200
6C78 Zone X Summation MSGF Alarm Pickup Set-
ting (16 items) 30 to 1200 --- 10 F001 1200
6C88 Zone X Summation MSGF Trip or Open 0 to 1 --- 1 F727 0
6C89 Zone X Summation Reserved (32 items) F001
6CA9 ...Repeated for module number 2
Options (Read Only)
6D4A Reserved (242 items) --- --- --- F076 "0"
6E3C Options Authentication State 0 to 2 --- 1 F738 0 (Invalid)
6E3D Options Timestamp 0 to 4294967295 --- 1 F050 0
6E3F Options Bit Vectors 0 to 65535 --- 1 F728 0
6E40 Options Expanded Metering Count 0 to 30 --- 1 F001 0
6E41 Option Expanded Metering Node x State
Enable 0 to 4294967295 --- 1 F722 0
6E43 Option Demand Metering Count 0 to 30 --- 1 F001 0
6E44 Option Demand Metering Node x State
Enable 0 to 4294967295 --- 1 F722 0
6E46 Option Harmonics Metering Count 0 to 30 --- 1 F001 0
6E47 Option Harmonics Metering Node x State
Enable 0 to 4294967295 --- 1 F722 0
6E49 Option Voltage Relay Count 0 to 30 --- 1 F001 0
6E4A Option Voltage Relay Node x State Enable 0 to 4294967295 --- 1 F722 0
6E4C Option High Current Relay Count 0 to 30 --- 1 F001 0
6E4D Option High Current Relay Node x State
Enable 0 to 4294967295 --- 1 F722 0
