Alarm X Over Demand Flex Enable

0 to 1

---

F102

0 (Disabled)

8E5A

Alarm X Over Demand Flex Pickup Setting

-5000 to 5000

100

F002

1500

8E5B

Alarm X Over Demand Flex Interval

1 to 15

---

F001

8E5C

Alarm X Over Demand Flex Subinterval

1 to 900

F001

8E5D

Alarm X Under Demand Flex Enable

0 to 1

---

F102

0 (Disabled)

8E5E

Alarm X Under Demand Flex Pickup Setting

-5000 to 5000

100

F002

500

8E5F

Alarm X Under Demand Flex Interval

1 to 15

---

F001

8E60

Alarm X Under Demand Flex Subinterval

1 to 900

F001

8E61

Flex Relay Settings Reserved 3

8E71

…Repeated for module 2

8EA3

…Repeated for module 3

8ED5

…Repeated for module 4

8F07

…Repeated for module 5

8F39

…Repeated for module 6

8F6B

…Repeated for module 7

8F9D

…Repeated for module 8

8FCF

…Repeated for module 9

9001

…Repeated for module 10

9033

…Repeated for module 11

9065

…Repeated for module 12

9097

…Repeated for module 13

90C9

…Repeated for module 14

90FB

…Repeated for module 15

912D

…Repeated for module 16

SRC X Restricted Breaker Control Registers
(Read / Write)

94E3

SRC x Open Breaker by Restricted Control

2 to 65535

---

F126

0 (No)

94E4

SRC x Close Breaker by Restricted Control

2 to 65535

---

F126

0 (No)

94E5

SRC x Trip Breaker by Restricted Control

2 to 65535

---

F126

0 (No)

94E6

Reserved (2 items)

94E8

...Repeated for module number 2

94ED

...Repeated for module number 3
