Modbus Memory Map 92
4 6650 Zone X MSGF Alarm I2T Curve (16 items) 0 to 1 --- 1 F725 0
6660 Zone X MSGF Trip Enabled (16 items) 0 to 1 --- 1 F102 0
6670 Zone X MSGF Alarm Enabled (16 items) 0 to 1 --- 1 F102 0
6680 Zone X MSGF Backup Enabled (16 items) 0 to 1 --- 1 F102 0
6690 Zone X MSGF Backup Time Date Enabled (16
items) 0 to 1 --- 1 F102 0
66A0 Zone X MSGF Trip or Open 0 to 1 --- 1 F727 0
66A1 Zone X MSGF Reserved (16 items) F001
66B1 ...Repeated for module number 2
6762 ...Repeated for module number 3
6813 ...Repeated for module number 4
Zone X BD Settings (Read/Write Setting) (4 modules)
68C4 Zone X BD Trip Pickup Setting (16 items) 100 to 22000 --- 100 F001 1200
68D4 Zone X BD Alarm Pickup Setting (16 items) 100 to 22000 --- 100 F001 1200
68E4 Zone X BD Trip Pickup Setting2 (16 items) 100 to 22000 --- 100 F001 1200
68F4 Zone X BD Alarm Pickup Setting2 (16 items) 100 to 22000 --- 100 F001 1200
6904 Zone X BD Trip Delay Band Setting (16 items) 0 to 6 --- 1 F713 2
6914 Zone X BD Alarm Delay Band Setting (16
items) 0 to 6 --- 1 F713 2
6924 Zone X BD Trip Delay Band Setting2 (16
items) 0 to 6 --- 1 F713 2
6934 Zone X BD Alarm Delay Band Setting2 (16
items) 0 to 6 --- 1 F713 2
6944 Zone X BD Trip Enabled (16 items) 0 to 1 --- 1 F102 0
6954 Zone X BD Alarm Enabled (16 items) 0 to 1 --- 1 F102 0
6964 Zone X BD Backup Enabled (16 items) 0 to 1 --- 1 F102 0
6974 Zone X BD Backup Time Delta Enabled (16
items) 0 to 1 --- 1 F102 0
6984 Zone X BD Trip or Open 0 to 1 --- 1 F727 0
6985 Zone X BD Reserved (16 items) F001
6995 ...Repeated for module number 2
6A66 ...Repeated for module number 3
6B37 ...Repeated for module number 4
Zone X Summation Settings (Read/Write Setting) (2 modules)
