Modbus Memory Map Format Codes
144
5
[44] NOR (2-16 INPUTS)
[46] NAND (2-16 INPUTS)
[48] TIMER (1-32)
[50] ASSIGN VIRTUAL OUTPUT (1 - 64)
[52] SELF-TEST ERROR (See F141 for range)
[56] ACTIVE SETTING GROUP (1-8)
[62] MISCELLANEOUS EVENTS (See F146 for range)
[64-127] ELEMENT STATES (Refer to Memory Map Element States Section)
F500
UINT16
PACKED BITFIELD
First register indicates I/O state with bits 0(MSB)-15(LSB) corresponding to I/0 state 1-16.
Second register indicates I/O state with bits 0-15 corresponding to I/0 state 17-32 (if
required). Third register indicates I/O state with bits 0-15 corresponding to I/0 state 33-48
(if required). Fourth register indicates I/O state with bits 0-15 corresponding to I/0 state
49-64 (if required). The number of registers required is determined by the specific data
item.
A bit value of 0 = Off, 1 = On
F701
BITFIELD
SRCx Node Internal Diagnostics Bit Mask
0
Power-on Self Test Error Detected
1
Built-In-Test Error Detected
2
Invalid
Data
Detected
3
Jamb sync occurred over threshold
4
Invalid node configuration detected
5
Invalid CRC check of node firmware
6
IButton
Missing
7
EEPROM
Configuration
Invalid
8
Not
Used
9
Not
Used
10
Not
Used
11
Not
Used
Format Name Format Type/Bitmask
Format Definition
