Modbus Memory Map
104
4
8D03
...Repeated for module number 127
8D21
...Repeated for module number 128
Force Contact Inputs (Read/Write Setting) (128 Modules)
8D3F
Force Contact Input x State (128 items)
0 to 2
---
1
F144
0 (Disabled)
Force Contact Outputs (Read/Write Setting) (128 Modules)
8DBF
Force Contact Output x State (128 items)
0 to 3
---
1
F131
0 (Disabled)
Flex Relay Settings (Read/Write Settings) (16 Modules)
8E3F
Relay X High Curr Flex Alarm Breaker Selec-
tion
0 to 30
---
1
F001
30
8E40
Relay X High Curr Flex Alarm Enable
0 to 1
---
1
F102
0
8E41
Relay X High Curr Flex Alarm Pickup Setting
10 to 200
%
5
F001
200
8E42
Relay X High Curr Flex Alarm Time Delay
1 to 15
S
1
F001
15
8E43
Flex Relay Settings Reserved
8E45
Relay X UV Flex Voltage Source
0 to 30
---
1
F001
30
8E46
Relay X UV Flex Breaker To Trip
0 to 30
---
1
F001
30
8E47
Relay X UV Flex Trip Enable
0 to 1
---
1
F102
0 (Disabled)
8E48
Relay X UV Flex Trip Pickup Setting
10 to 95
%
1
F001
10
8E49
Relay X UV Flex Trip Time Delay
0.5 to 600
S
0.5
F001
30
8E4A
Relay X UV Flex Trip Phase Requirement
1 to 3
---
1
F001
1
8E4B
Relay X UV Flex Trip Curve Type
0 to 1
---
1
F726
1
8E4C
Relay X UV Flex Trip Blocking Voltage Enable
0 to 1
---
1
F102
0 (Disabled)
8E4D
Relay X UV Flex Trip Blocking Voltage Setting
5 to 75
%
1
F001
5
8E4E
Relay X UV Flex Trip or Open Setting
0 to 1
---
1
F727
1
8E4F
Relay X UV Flex Alarm Enable
0 to 1
---
1
F102
0 (Disabled)
8E50
Relay X UV Flex Alarm Pickup Setting
10 to 95
%
1
F001
10
8E51
Relay X UV Flex Alarm Time Delay
0.5 to 600
S
0.5
F001
15
8E52
Relay X UV Flex Alarm Phase Requirement
1 to 3
---
1
F001
1
8E53
Relay X UV Flex Alarm Curve Type
0 to 1
---
1
F726
1
8E54
Relay X UV Flex Alarm Blocking Voltage
Enable
0 to 1
---
1
F102
0 (Disabled)
8E55
Relay X UV Flex Alarm Blocking Voltage Set-
ting
5 to 75
%
1
F001
5
8E56
Flex Relay Settings Reserved 2
8E58
Alarm X Demand Flex Breaker Selection
0 to 30
---
1
F001
30
