GE Industrial Solutions Entellisys 5.0 Integrator's Guide - Manual (Page 61)

61
4 Source Status Vectors (Read Only)
040A Expected Nodes x State 0 to 4294967295 --- 1 F722 0
040C Source Node Identifier LED x State 0 to 4294967295 --- 1 F722 0
040E Node Setting Changed x State 0 to 4294967295 --- 1 F722 0
0410 Nodes Communicating x State 0 to 4294967295 --- 1 F722 0
0412 Nodes Commissioned x State 0 to 4294967295 --- 1 F722 0
0414 Duplicate Nodes x State 0 to 4294967295 --- 1 F722 0
0416 Node Internal Diagnostics x State 0 to 4294967295 --- 1 F722 0
0418 Node System Diagnostics x State 0 to 4294967295 --- 1 F722 0
041A Node Hardware Diagnostics x State 0 to 4294967295 --- 1 F722 0
041C Node Reflected CPU Diagnostics x State 0 to 4294967295 --- 1 F722 0
041E Breaker Contact Position x State 0 to 4294967295 --- 1 F722 0
0420 Breaker Primary Connection x State 0 to 4294967295 --- 1 F722 0
0422 Breaker Lockout x State 0 to 4294967295 --- 1 F722 0
0424 Summations Suspended X State 0 to 4294967295 --- 1 F722 0
0426 Breaker Tripped x State 0 to 4294967295 --- 1 F722 0
Source Vectors for Alarms
(Ack are R/W)
0428 Undervoltage Trip Alarm State 0 to 4294967295 --- 1 F722 0
042A Undervoltage Trip Alarm Ack 0 to 4294967295 --- 1 F722 0
042C Undervoltage Alarm State 0 to 4294967295 --- 1 F722 0
042E Undervoltage Alarm Ack 0 to 4294967295 --- 1 F722 0
0430 Overvoltage Trip Alarm State 0 to 4294967295 --- 1 F722 0
0432 Overvoltage Trip Alarm Ack 0 to 4294967295 --- 1 F722 0
0434 Overvoltage Alarm State 0 to 4294967295 --- 1 F722 0
0436 Overvoltage Alarm Ack 0 to 4294967295 --- 1 F722 0
0438 Phase Loss Trip Alarm State 0 to 4294967295 --- 1 F722 0
043A Phase Loss Trip Alarm Ack 0 to 4294967295 --- 1 F722 0
043C Phase Loss Alarm State 0 to 4294967295 --- 1 F722 0
043E Phase Loss Alarm Ack 0 to 4294967295 --- 1 F722 0
0440 Reverse Power Trip Alarm State 0 to 4294967295 --- 1 F722 0
0442 Reverse Power Trip Alarm Ack 0 to 4294967295 --- 1 F722 0
0444 Reverse Power Alarm State 0 to 4294967295 --- 1 F722 0
