Modbus Memory Map
88
4
505F
Synch Check Max Freq Diff
0 to 2.0
Hz
0.1
F001
0
5060
Synch Check Dead Max V1
5 to 50
%
1
F001
5
5061
Synch Check Live Min V1
50 to 100
%
1
F001
50
5062
Synch Check Dead MaxV2
5 to 50
%
1
F001
5
5063
Synch Check Live Min V2
50 to 100
%
1
F001
50
5064
Reserved (4 items)
---
---
---
---
---
5068
Synch Check Dead Source Select
0 to 5
---
1
F176
0 (None selected)
5069
Synch Check Status
0 to 65535
---
1
F001
0
506A
Synch Check Reserved (14 items)
5078
...Repeated for module number 2
5096
...Repeated for module number 3
50B4
...Repeated for module number 4
50D2
...Repeated for module number 5
50F0
...Repeated for module number 6
510E
...Repeated for module number 7
512C
...Repeated for module number 8
514A
...Repeated for module number 9
5168
...Repeated for module number 10
5186
...Repeated for module number 11
51A4
...Repeated for module number 12
ZSI Options Settings (Read/Write Setting)
51C2
ZSI Option
0 to 2
---
1
F732
0
ZSI Zone Enables (Read/Write Setting) (4 Modules)
51C4
ZSI Zone X Enabled
0 to 1
---
1
F126
0
51C5
ZSI Zone Enable Reserved (4 items)
51C9
...Repeated for module number 2
51CE
...Repeated for module number 3
51D3
...Repeated for module number 4
Simple Network Time Protocol (Read/Write)
51DD
Simple Network Time Protocol (SNTP) Server
IP Address
0 to 4294967295
---
1
F003
0
