Supported function codes 55
3
d. Reading waveform capture files
Waveform records comply with COMTRADE 1999 format (IEEE Std C37.111-1999). The file
names as required by the standard for waveform capture data are wfc#####.dat and
wfc#####.cfg. The ##### refers to the waveform record number. Note that this number
is not the same as the event number cited in the case of the fault report above. If an
event has a waveform capture associated with it, the waveform number will be shown in
the WF Number field as indicated in the header of the event log.
