Multipoint FlexLogic Operand States
41
2
2.2.5 Reduced Energy Let - Thru Operand States
This relay has 1 state shown in
Table 2-40
.
Table 2-40 Multi Point RELT status bit field
The relay state uses one modbus register as shown in
Table 2-41
. See
Table 2-41 RELT status offsets
Bit
Value
0
Multipoint Reduced Let-Thru Mode On
Zone Number
Register
Offset
Bit Offset
Breaker 1 Single Point RELT
0
0
Breaker 2 Single Point RELT
0
1
Breaker 3 Single Point RELT
0
2
Breaker 4 Single Point RELT
0
3
Breaker 5 Single Point RELT
0
4
Breaker 6 Single Point RELT
0
5
Breaker 7 Single Point RELT
0
6
Breaker 8 Single Point RELT
0
7
Breaker 9 Single Point RELT
0
8
Breaker 10 Single Point RELT
0
9
Breaker 11 Single Point RELT
0
10
Breaker 12 Single Point RELT
0
11
Breaker 13 Single Point RELT
0
12
Breaker 14 Single Point RELT
0
13
Breaker 15 Single Point RELT
0
14
Breaker 16 Single Point RELT
0
15
Breaker 17 Single Point RELT
1
0
Breaker 18 Single Point RELT
1
1
Breaker 19 Single Point RELT
1
2
Breaker 20 Single Point RELT
1
3
Breaker 21 Single Point RELT
1
4
Breaker 22 Single Point RELT
1
5
Breaker 23 Single Point RELT
1
6
Breaker 24 Single Point RELT
1
7
