GE Industrial Solutions Entellisys 5.0 Integrator's Guide - Manual (Page 141)

141
5
5 Modbus Memory Map Format Codes
Format Name Format Type/Bitmask Format Definition
F001 UINT16 UNSIGNED 16 BIT INTEGER
F002 SINT16 SIGNED 16 BIT INTEGER
F003 UINT32 UNSIGNED 32 BIT INTEGER (2 registers)
High order word is stored in the first register.
Low order word is stored in the second register.
F004 SINT32 SIGNED 32 BIT INTEGER (2 registers)
High order word is stored in the first register.
Low order word is stored in the second register.
F013 POWER_FACTOR POWER FACTOR (SIGNED 16 BIT INTEGER)
Positive values indicate lagging power factor; negative values indicate leading.
F050 UINT32 TIME and DATE (UNSIGNED 32 BIT INTEGER)
Gives the current time in seconds elapsed since 00:00:00 January 1, 1970.
F060 FLOATING_POINT IEEE FLOATING POINT (32 bits)
F072 HEX6 6 BYTES - 12 ASCII DIGITS
F102 ENUMERATION DISABLED/ENABLED
0 Disabled
1 Enabled
F106 ENUMERATION PHASE ROTATION
0 ABC
1 ACB
F108 ENUMERATION OFF/ON
0 Off
1 On
