157
5
23 55 - I/O x + (bit number) Input, 1 - I/O x + (bit number) Output
24 56 - I/O x + (bit number) Input, 1 - I/O x + (bit number) Output
25 57 - I/O x + (bit number) Input, 1 - I/O x + (bit number) Output
26 58 - I/O x + (bit number) Input, 1 - I/O x + (bit number) Output
27 59 - I/O x + (bit number) Input, 1 - I/O x + (bit number) Output
28 60 - I/O x + (bit number) Input, 1 - I/O x + (bit number) Output
29 61 - I/O x + (bit number) Input, 1 - I/O x + (bit number) Output
30 62 - I/O x + (bit number) Input, 1 - I/O x + (bit number) Output
31 63 - I/O x + (bit number) Input, 1 - I/O x + (bit number) Output
F738 ENUMERATION Option String Authentication Status
0 New and Old Both Option strings Invalid
1 Using Valid New Option String
2 Using Valid Old Option String
F739 Bit Field Reduced Let Thru Bit Vector
0 Bit field representing 0 or 1 for Node 0 RELT
1 Bit field representing 0 or 1 for Node 1 RELT
2 Bit field representing 0 or 1 for Node 2 RELT
3 Bit field representing 0 or 1 for Node 3 RELT
4 Bit field representing 0 or 1 for Node 4 RELT
5 Bit field representing 0 or 1 for Node 5 RELT
6 Bit field representing 0 or 1 for Node 6 RELT
7 Bit field representing 0 or 1 for Node 7 RELT
8 Bit field representing 0 or 1 for Node 8 RELT
9 Bit field representing 0 or 1 for Node 9 RELT
10 Bit field representing 0 or 1 for Node 10 RELT
11 Bit field representing 0 or 1 for Node 11 RELT
Format Name Format Type/Bitmask Format Definition
