Modbus Memory Map 84
4 3804 SRC X Rev Power Alarm Pickup Setting 10 to 990 kW 10 F001 990
3805 SRC X Rev Power Alarm Time Delay 0.5 to 600 S 0.5 F001 15
3806 SRC X Rev Power Trip or Open 0 to 1 --- 1 F727 1
3807 Source Settings Reserved 4 (4 items)
380B SRC X High Curr Alarm Enable 0 to 1 --- 1 F102 0
380C SRC X High Curr Alarm Pickup Setting 50 to 200 % 5 F001 200
380D SRC X High Curr Alarm Time Delay 1 to 15 S 1 F001 15
380E Source Settings Reserved 5 (5 items)
3813 SRC X Total Breaker Operations 0 to 65535 --- 1 F001 0
3814 SRC X Total Breaker No Load Operations 0 to 65535 --- 1 F001 0
3815 SRC X Total Breaker Load Operations 0 to 65535 --- 1 F001 0
3816 SRC X Total Breaker Fault Operations 0 to 65535 --- 1 F001 0
3817 SRC X Breaker Percent Load Life 0 to 65535 --- 1 F001 0
3818 SRC X Percent Mechanical Life 0 to 65535 --- 1 F001 0
3819 SRC X Time Date Last Breaker Operation 0 to 4294967295 --- F050 0
381B SRC X Time Date Initial Energization 0 to 4294967295 --- F050 0
381D SRC X Breaker Service Hours 0 to 4294967295 --- 1 F003 0
381F Source Settings Reserved 5 (5 items)
3824 SRC X UF Trip Enable 0 to 1 --- 1 F102 0
3825 SRC X UF Trip Pickup Setting 45 to 60 Hz 1 F001 45
3826 SRC X UF Trip Time Delay 0.1 to 600 S 0.1 F001 30
3827 SRC X UF Trip Blocking Voltage Enable 0 to 1 --- 1 F102 0
3828 SRC X UF Trip or Open setting 0 to 1 --- 1 F727 1
3829 SRC X UF Alarm Enable 0 to 1 --- 1 F102 0
382A SRC X UF Alarm Pickup Setting 45 to 60 Hz 1 F001 45
382B SRC X UF Alarm Time Delay 0.1 to 600 --- 0.1 F001 15
382C SRC X UF Alarm Blocking Voltage Enable 0 to 1 --- 1 F102 0
382D SRC X OF Trip Enable 0 to 1 --- 1 F102 0
382E SRC X OF Trip Pickup Setting 50 to 70 Hz 1 F001 70
382F SRC X OF Trip Time Delay 0.1 to 600 S 0.1 F001 30
3830 SRC X OF Trip Blocking Voltage Enable 0 to 1 --- 1 F102 0
3831 SRC X OF Trip or Open setting 0 to 1 --- 1 F727 1
