81

4

2B29

SRC X Node System Diagnostics 2

0 to 65535

---

1

F703

0

2B2A

SRC X Node Hardware Diagnostics

0 to 65535

---

1

F704

0

2B2B

SRC X Node Physical Status

0 to 65535

---

1

F708

0

2B2C

SRC X Node Logic and Trip Status

0 to 65535

---

1

F709

0

2B2D

SRC X Node Last Trip Sequence Number

0 to 4294967295

---

1

F003

0

2B2F

SRC X Reflected CPU Diagnostics

0 to 65535

---

1

F706

0

2B30

SRC X Reflected CPU 0 Command

0 to 65535

---

1

F707

0

2B31

SRC X Reflected CPU 1 Command

0 to 65535

---

1

F707

0

2B32

SRC X Fan Status

0 to 1

---

1

F108

0

2B33

SRC X CT Rating Node Report

0 to 65535

---

1

F001

0

2B34

SRC X Node Serial Number

---

---

---

F205

" "

2B3A

SRC X Phase A Frequency

0 to 655.35

Hz

0.01

F001

0

2B3B

SRC X Phase B Frequency

0 to 655.35

Hz

0.01

F001

0

2B3C

SRC X Phase C Frequency

0 to 655.35

Hz

0.01

F001

0

2B3D

SRC X Topology

0 to15

---

1

F001

1

2B3E

SRC X ST ZSI Current Restrained Time

0 to 65535

ms

1

F001

0

2B3F

SRC X NodeProt ZSI Peak to Peak IOC Setting

0 to 48

1/2

Cycle

1

F001

0

2B40

Reserved (2 items)

F001

0

2B66

...Repeated for module number 2

2BB6

...Repeated for module number 3

2C06

...Repeated for module number 4

2C56

...Repeated for module number 5

2CA6

...Repeated for module number 6

2CF6

...Repeated for module number 7

2D46

...Repeated for module number 8

2D96

...Repeated for module number 9

2DE6

...Repeated for module number 10

2E36

...Repeated for module number 11

2E86

...Repeated for module number 12

2ED6

...Repeated for module number 13

2F26

...Repeated for module number 14
