Modbus Memory Map 138
4 E19F ...Repeated for module number 28
E1BF ...Repeated for module number 29
E1DF ...Repeated for module number 30
Source Group Settings (Read/Write Settings) (30 Modules)
E1FF SRC X IOC Enabled (16 items) 0 to 1 --- 1 F718 1
E20F SRC X IOC Pickup Setting Multiplier (16 items) 1.5 - 15 --- 0.5 F001 6
E21F SRC X Short Time Protection Switch (16
items) 0 to 1 --- 1 F102 1
E22F SRC X Short Time Pickup Setting (16 items) 1.5 to 9.0 --- 0.5 F001 4
E23F SRC X Short Time I2T Curve (16 items) 0 to 2 --- 1 F725 0
E24F SRC X Short Time Delay Band Setting (16
items) 0 to 6 --- 1 F713 2 (band 3)
E25F SRC X Long Time Delay Band Setting (16
items) 0 to 3 --- 1 F711 1 (band 2)
E26F SRC X GF Protection Switch (16 items) 0 to 1 --- 1 F102 0
E27F SRC X GF Protection Trip Pickup Setting (16
items) .2 to.6 --- 0.01 F001 0.24
E28F SRC X GF Protection Trip I2T Curve (16 items) 0 to 1 --- 1 F102 1
E29F SRC X GF Protection Trip Delay Band Setting
(16 items) 0 to 6 --- 1 F713 2 (band 3)
E2AF SRC X GF Protection Trip Priority (16 items) 0 to 30 --- 1 F001 0
E2BF SRC X GF Protection Alarm Enable (16 items) 0 to 1 --- 1 F102 0
E2CF SRC X GF Protection Alarm Pickup Setting
(16 items) 0.2 to 0.6 --- 0.01 F001 0.24
E2DF SRC X GF Protection Alarm I2T Curve (16
items) 0 to 1 --- 1 F102 1
E2EF SRC X GF Protection Alarm Delay Band Set-
ting (16 items) 0 to 6 --- 1 F713 2 (band 3)
E2FF ...Repeated for module number 2
E3FF ...Repeated for module number 3
E4FF ...Repeated for module number 4
E5FF ...Repeated for module number 5
E6FF ...Repeated for module number 6
E7FF ...Repeated for module number 7
E8FF ...Repeated for module number 8
