GE Industrial Solutions Entellisys 5.0 Integrator's Guide User Manual
Page 85
85
4
3832
SRC X OF Alarm Enable
0 to 1
---
1
F102
0
3833
SRC X OF Alarm Pickup Setting
50 to 70
Hz
1
F001
50
3834
SRC X OF Alarm Time Delay
0.1 to 600
---
0.1
F001
15
3835
SRC X OF Alarm Blocking Voltage Enable
0 to 1
---
1
F102
0
3836
SRC X HRGF Enable
0 to 1
---
1
F102
0
3837
SRC X HRGF Pickup
0.1 to 10
---
0.1
F001
2
3838
SRC X HRGF Delay
0.5 to 5
---
0.1
F001
0.5
3839
SRC X HRGF Ground Resistance
5 to 500
---
1
F001
5
383A
SRC X HRGF CT Rating
10 to 10
---
1
F001
10
383B
Reserved (8 items)
---
---
---
---
---
3843
SRC X High Curr Trigger Alarm Enable
0 to 1
---
1
F102
0
3844
SRC X High Curr Trigger Alarm Pickup Set-
ting
0.1 to 9
---
0.1
F001
2
3845
SRC X High Curr Trigger Alarm Delay Setting
1 to 120
---
1
F001
12
3846
SRC X High Curr Trigger Alarm WFC Enable
0 to 1
---
1
F102
0
3847
SRC X High Curr Trigger Alarm Max WF
0 to 30
---
1
F001
15
3848
SRC X High Curr Trigger Alarm WF Triggered
0 to 30
---
1
F001
0
3849
SRC X High Curr Trigger Alarm WF Count
Reset
0 to 1
---
1
F126
0
384A
SRC X Settings Reserved (40 items)
3872
...Repeated for module number 2
3926
...Repeated for module number 3
39DA
...Repeated for module number 4
3A8E
...Repeated for module number 5
3B42
...Repeated for module number 6
3BF6
...Repeated for module number 7
3CAA
...Repeated for module number 8
3D5E
...Repeated for module number 9
3E12
...Repeated for module number 10
3EC6
...Repeated for module number 11
3F7A
...Repeated for module number 12
402E
...Repeated for module number 13
40E2
...Repeated for module number 14
