Modbus Memory Map
82
4
2F76
...Repeated for module number 15
2FC6
...Repeated for module number 16
3016
...Repeated for module number 17
3066
...Repeated for module number 18
30B6
...Repeated for module number 19
3106
...Repeated for module number 20
3156
...Repeated for module number 21
31A6
...Repeated for module number 22
31F6
...Repeated for module number 23
3246
...Repeated for module number 24
3296
...Repeated for module number 25
32E6
...Repeated for module number 26
3336
...Repeated for module number 27
3386
...Repeated for module number 28
33D6
...Repeated for module number 29
3426
...Repeated for module number 30
SRCx Node Counters (Read/Write) - Write a 0 to these to reset them
3476
Reserved (840 items)
0 to 65535
---
1
F001
0
SRCx Settings (Read/Write)
37BE
SRC X Node Commissioned
0 to 1
---
1
F102
0
37BF
SRC X PT Source Node Identifier
0 to 29
---
1
F001
0
37C0
SRC X Breaker Connection
0 to 1
---
1
F712
0
37C1
Reserved (17 items)
37D2
SRC X PT Rating
0 to 6
---
1
F719
0
37D3
SRC X UV Trip Enable
0 to 1
---
1
F102
0
37D4
SRC X UV Trip Curve Type
0 to 1
---
1
F726
1
37D5
SRC X UV Trip Pickup Setting
10 to 95
%
1
F001
50
37D6
SRC X UV Trip Time Delay
0.5 to 600
S
0.5
F001
30
37D7
SRC X UV Trip Phase Requirement
1 to 3
---
1
F001
1
37D8
SRC X UV Trip Block Volt Enable
0 to 1
---
1
F102
0
37D9
SRC X UV Trip Block Volt Setting
5 to 75
%
1
F001
5
37DA
SRC X UV Trip Open or Trip Setting
0 to 1
---
1
F727
1
