Modbus Memory Map
80
4
2902
...Repeated for module number 17
2928
...Repeated for module number 18
294E
...Repeated for module number 19
2974
...Repeated for module number 20
299A
...Repeated for module number 21
29C0
...Repeated for module number 22
29E6
...Repeated for module number 23
2A0C
...Repeated for module number 24
2A32
...Repeated for module number 25
2A58
...Repeated for module number 26
2A7E
...Repeated for module number 27
2AA4
...Repeated for module number 28
2ACA
...Repeated for module number 29
2AF0
...Repeated for module number 30
SRCx As Reported At Node Status (Read Only)
2B16
SRC X Node ID
0 to 29
---
1
F001
0
2B17
Reserved (3 items)
---
---
---
F072
0
2B1A
SRC X Frame Rating
0 to 65535
---
1
F001
0
2B1B
SRC X CT Rating
0 to 65535
---
1
F001
0
2B1C
SRC X Breaker Type
0 to 65535
---
1
F715
0
2B1D
SRC X NodeProt Protection Config
0 to 255
---
---
F705
0
2B1E
SRC X Node Firmware Version
0 to 655.35
---
0.01
F001
0
2B1F
SRC X Hardware Version
0 to 255
---
1
F001
0
2B20
SRC X Message Protocol Version
0 to 65535
---
1
F001
0
2B21
SRC X Product Type
0 to 65535
---
1
F716
0
2B22
SRC X NodeProt Rating Switch
0 to 65535
---
1
F001
0
2B23
SRC X NodeProt Long Time Setting Multiplier
0 to 655.35
---
0.01
F001
0
2B24
SRC X NodeProt IOC Threshold Setting
0 to 655.35
---
0.01
F001
0
2B25
SRC X NodeProt Ground Fault Setting
0 to 655.35
---
0.01
F102
0
2B26
SRC X NodeProt Short Time Setting
0 to 6553.5
---
0.1
F102
0
2B27
SRC X Node Internal Diagnostics
0 to 65535
---
1
F701
0
2B28
SRC X Node System Diagnostics 1
0 to 65535
---
1
F702
0
