18.2 Analog digital converters measurements +ADC
18.2.1 Description:
This command gets the (DC level * 1024) of ADC A, ADC B, and possibly ADC C. These voltages are
coded on 12 bits..
18.2.2 Syntax :
Command syntax : AT+ADC=
Response syntax : +ADC: ,[,]
Command
Possible responses
AT+ADC=?
Note : Ask for the list of possible values +ADC: (0-1)
Note : possible values 0 or 1
AT+ADC=0
Note : Select 2 converters (mode 0) OK
Note : 2 converters mode selected
AT+ADC?
Note : Ask for the current values of converters in
mode 0 +ADC: 500,23
OK
Note : Adc A, Adc B on 12 bits
AT+ADC=1
Note : Select 3 converters (mode 1) OK
Note : 3 converters mode selected
AT+ADC?
Note : Ask for the current values of converters in
mode 1 +ADC: 712,23,23
OK
Note: Adc A, Adc B, Adc C on 12 bits
18.2.3 Defined values:
0 : Select 2 converters
1 : Select 3 converters
ADC A value, coded on 12 bits. The value returned includes the resistor bridge.
These values are updated every 10 seconds. Displayed on modes 0 and 1.
ADC B value, coded on 12 bits. Displayed on modes 0 and 1.
ADC C value, coded on 12 bits. Displayed only on mode 1.
