FLYFOT-M260-MODULE
Page: 168 / 239
This document is the sole and exclusive property of FLYFOT. Not to be distributed or divulged without
prior written agreement.
Reference Note
17.15 AT+CDNSORIP
AT+CDNSORIP
Set Link the SERVER is IP address or domain name
Set command
AT+ CDNSORIP=
Response
OK
AT+
CDNSORIP=1 OK
Note
: Set Link the SERVER is domain name
Query command
AT+CDNSORIP?
Response
1
OK
Parameter
:
0:
Set Link the SERVER is IP address.
1: Set Link the SERVER is domain name .
Reference Note
17.16 TCP/IP Examples
17.16.1 以 GPRS 方式连接到 SERVER 端 IP 地址并开始传送数据
1. AT+CIPCSGP=1,”CMNET”
2. AT+CIPSTART=”TCP”, 218.246.2.150,2020
3. AT+CIPSEND
4. AT+CIPCLOSE
5. AT+CIPSHUT
17.16.2 以 CSD 方式连接到 SERVER 端 IP 地址并开始传送数据
1. AT+CIPCSGP=0,17201,172,172,2
2. AT+CIPSTART=”TCP”, 218.246.2.150,2020
3. AT+CIPSEND
4. AT+CIPCLOSE
5. AT+CIPSHUT
17.16.3 连接到 SERVER 端 UDP 地址并开始传送数据
1. AT+CIPSTART=”UDP”, 218.246.2.150,3030
2. AT+CIPSEND
3. AT+CIPCLOSE
4. AT+CIPSHUT
