PIO Interrupt Disable Register
Register Name: PIO_IDR
Access Type: Write-only
This register is used to disable PIO interrupts on the corresponding pin. It has an effect whether the PIO is enabled or not.
1 = Disables the interrupt on the corresponding pin. Logic level changes are still detected.
0 = No effect.
PIO Interrupt Mask Register
Register Name: PIO_IMR
Access Type: Read-only
Reset Value: 0
This register shows which pins have interrupts enabled. It is updated when interrupts are enabled or disabled by writing to
PIO_IER or PIO_IDR.
1 = Interrupt is enabled on the corresponding pin.
0 = Interrupt is not enabled on the corresponding pin.
31 30 29 28 27 26 25 24
P31 P30 P29 P28 P27 P26 P25 P24
23 22 21 20 19 18 17 16
P23 P22 P21 P20 P19 P18 P17 P16
15 14 13 12 11 10 9 8
P15 P14 P13 P12 P11 P10 P9 P8
7 6 5 4 3 2 1 0
P7 P6 P5 P4 P3 P2 P1 P0
31 30 29 28 27 26 25 24
P31 P30 P29 P28 P27 P26 P25 P24
23 22 21 20 19 18 17 16
P23 P22 P21 P20 P19 P18 P17 P16
15 14 13 12 11 10 9 8
P15 P14 P13 P12 P11 P10 P9 P8
7 6 5 4 3 2 1 0
P7 P6 P5 P4 P3 P2 P1 P0
