AIC User Interface
Base Address: 0xFF030000
Note: 1. The reset value of this register depends on the level of the external IRQ lines. All other sources are cleared at reset.
Table 12. AIC Memory Map
Offset Register Description Register Name Access Reset State
0x000 Source Mode Register 0 AIC_SMR0 Read/write 0
0x004 Source Mode Register 1 AIC_SMR1 Read/write 0
– – – Read/write 0
0x07C Source Mode Register 31 AIC_SMR31 Read/write 0
0x080 Reserved – – –
0x084 Reserved – – –
– Reserved – – –
0x0FC Reserved – – –
0x100 IRQ Vector Register AIC_IVR Read-only 0
0x104 FIQ Vector Register AIC_FVR Read-only 0
0x108 Interrupt Status Register AIC_ISR Read-only 0
0x10C Interrupt Pending Register AIC_IPR Read-only (see Note 1)
0x110 Interrupt Mask Register AIC_IMR Read-only 0
0x114 Core Interrupt Status Register AIC_CISR Read-only 0
0x118 Reserved – – –
0x11C Reserved – – –
0x120 Interrupt Enable Command Register AIC_IECR Write-only –
0x124 Interrupt Disable Command Register AIC_IDCR Write-only –
0x128 Interrupt Clear Command Register AIC_ICCR Write-only –
0x12C Interrupt Set Command Register AIC_ISCR Write-only –
0x130 End of Interrupt Command Register AIC_EOICR Write-only –
