AT75C310
3
AT75C310 Pin Description
Table 2. AT75C310 Pin Description
Block
Pin Name
Type
Function
Common Bus
A[21:0]
O
Address Bus
D[15:0]
I/O
Data Bus
NREQ
I
Bus Request
NGNT
O
Bus Grant
Dynamic Memory
Controller
NRAS[1:0]
O
Row Address Strobe
NCAS[1:0]
O
Column Address Strobe
NDWE
O
DRAM Write Enable
NDOE
O
DRAM Output Enable
Static Memory
Controller
NCE[3:0]
O
Chip Selects
NWE[1:0]
O
Byte Select/Write Enable
NSOE
O
SRAM Output Enable
I/O Port A
PA[12:0]
I/O
General Purpose I/O Lines. Multiplexed with peripheral I/Os
I/O Port B
PB[9:0]
I/O
General Purpose I/O Lines. Multiplexed with peripheral I/Os
DSP Subsystem A
OakAIN[1:0]
I
OakDSPCore A User Inputs
OakAOUT[1:0]
O
OakDSPCore A User Outputs
DSP Subsystem B
OakBIN[1:0]
I
OakDSPCore B User Inputs
OakBOUT[1:0]
O
OakDSPCore B User Outputs
Timer/Counter 0
TCLK0
I
Timer 0 External Clock
TIOA0
I/O
Timer 0 Signal A
TIOB0
I/O
Timer 0 Signal B
Timer/Counter 1
TCLK1
I
Timer 1 External Clock
TIOA1
I/O
Timer 1 Signal A
TIOB1
I/O
Timer 1 Signal B
Watchdog
NWDOVF
O
Watchdog Overflow
Serial Peripheral
Interface
MISO
I/O
Master In/Slave Out
MOSI
I/O
Master Out/Slave In
SPCK
I/O
Serial Clock
NPCSS
I/O
Chip Select/Slave Select
NPSC1
O
Optional SPI Chip Select 1
