In the
"Audio configuration" tab you will be able to customize the audio routing parameters of the subject. See "Audio rout-
Figure 52: MXF Op1A destination subject options
12.2.3 XDCAM Flat destination
Overview
XDCAM Flat destination subjects allow you to create a fully compatible XDCAM destination. It is accessible only in
XDCAM mode. The main resolution, metadata XML and proxy files are stored side by side in the selected folder. Assuming
the clip name is "Myclip", the main resolution, metadata XML and proxy file names will be Myclip.mxf, MyclipM01.xml and
MyclipS01.mxf, respectively.
i
The MXF file format of the source file is preserved (Ingest or subclip on an SxS format will generate an SxS MXF file).
Creating an XDCAM Flat destination subject
n
Select "XDCAM Flat" in the "New subject" dialog box.
Figure 53: Selecting the new subject
n
A folder browser dialog will automatically open. Browse to the folder where you want to store your ingested
sequences. You can change the destination folder later by clicking on the
button on the top of the ingest panel.
Figure 54: Browsing the destination folder
