3.20 SPECIAL EFFECTS
Special Effect p.9.1
[F1]Paint/Target trans. : 00s05fr
[F2]Set color for : Cursor
[F3]Colour: White [F4]Y : 240
[F5]U : 128
[F6]V : 128
[F7]Split Screen Tracking: No
[Menu]Quit [Clr+F_]Dft [F9]PgUp
3.20.1 P
AINT
/T
ARGET
T
RANSITION
Possible values: 0s01fr to 5s00fr. Default: 0s05fr
This setting sets the duration of the Dissolve effect for the key in Painting and
Target Tracking modes.
3.20.2 S
ET
C
OLOUR
F
OR
Possible values: Cursor (default) / Wipe / Split.
This setting applies the default color to a specific tool: to the cursor, to the border
of the wipe effect or to the delimiter of the split screen.
3.20.3 C
OLOUR
Possible values: white (default), black, custom
This setting defines the color to assign to the cursor/wipe/split.
3.20.4 C
USTOM
C
OLOR
F3, F4, and F5 are used to set the border color for the split screen, the wipe effect
and the cursor
Custom Y: (0 – 360)
Default: 240
Custom U: (0 – 128)
Default: 128
Custom V: (0 – 128)
Default: 128
