10.04.B XSense – Version 10.04 – Configuration Manual
EVS Broadcast Equipment – January 2011
48
3.8.9 M
ARK
C
UE
P
OINTS
Possible values: Live (default) / Playback
Live: memorizes cue points based on the timecode of the LIVE input.
Playback: memorizes cue points based on the timecode of the field loaded on the
main play channel.
3.8.10 P
RE
-R
OLL
Range: from 0s01fr to 5s00fr. Default: 0s05fr
Pre-roll duration used when recalling a cue point.
3.8.11 R
ECORD
T
RAIN
OUT
S
Possible values: Play through (default) / Freeze
When this parameter is set to “Freeze”, and an OUT point is marked in a record
train, Multicam will countdown to the OUT point and automatically freeze on that
picture (if the Post-Roll mode is disabled) or on that picture + the Post-Roll
duration (if the Post-Roll mode is enabled) when replaying that section.
When the parameter is set to “Play through”, Multicam will still countdown to the
OUT point, but will keep playing through this point. In a clip, Multicam always
freezes on the OUT point (or OUT point + Post-Roll duration when Post-Roll mode
is enabled).
3.8.12 F
REEZE ON
C
UE
P
OINTS
Possible values: No (default) / Yes
The purpose of this functionality is to allow marking cue points on any field of a
record train and freeze on the cue point when the playback reaches it. This is
similar to the freeze on OUT point functionality but because it will be done on cue
point, you will be able to freeze on any field (impossible with OUT points).
When playing record trains where cue points have been marked, the playout
freezes on the cue point if the parameter is set to “Yes”. It plays through if the
parameter is set to “No”.
The Post-Roll parameter is not taken into account for this functionality.
Record Trains p.2.3
[F1]Internal Loop Mode : Video+Audio
[F2]Make Clip rem. Trains : Ctrled Cams
[Menu]Quit [Clr+F_]Dft [F9]PgUp [F0]PgDn
