XSense – Version 10.04 – Configuration Manual
EVS Broadcast Equipment – January 2011
Issue
10.04.B
3
Setup page and section
name Content
Page 6
See section 2.8 ‘HCTX
Gigabit Connection Settings
(Page 6)’, on page 27 and 2.9
‘LAN Connection Settings
(Page 6)’, on page 29. It includes detailed settings on:
the HCTX gigabit connection
the MTPC board connection
Page 7
See section 2.10 ‘Sony
BVW75 Settings (Page 7)’ on
page 31.
It includes the settings used with the Sony BVW
protocol.
Page 8/9
See section 2.11 'EditRec
Settings (Page 8/9)’ on page
33.
It includes the settings used with the EditRec
application.
Page 10
See section 2.12 ‘Multiviewer
Settings (Page 10)’ on page
37.
It includes the settings for the connection of an
external multiviewer.
2.1.2 H
OW TO
A
CCESS THE
S
ETUP
C
ONFIGURATION
The Setup Configuration module is available by pressing simultaneously SHIFT-F2
on the keyboard with CAPS LOCK disabled. The Setup Configuration is not
accessible if CAPS LOCK is ON.
2.1.3 H
OW TO
M
OVE
I
NSIDE THE
S
ETUP
C
ONFIGURATION
• Use / SHIFT- to move from one parameter to the next/previous,
and the ←/→ arrow keys to change the value of a parameter.
• Use Page Up / Page Down to access the other configuration screens.
2.2 GENERAL SETTINGS (PAGE 1)
2.2.1 I
NTRODUCTION
The first page of the Setup Configuration module contains some parameters from
the Setup menu of the XSense Remote Panel that are useful to adjust when
working in a Spotbox mode.
If you modify the values for parameters available both in the Setup menu of the
Remote Panel and in the Setup Configuration menu, the changes are reflected
