XSense – Version 10.04 – Configuration Manual
EVS Broadcast Equipment – January 2011
Issue
10.04.B
5
is faulty.
Note
The server is equipped with a RAID disk array. This means that the
operation can continue seamlessly even with 1 faulty disk. If 1 disk is
disconnected during operation, the “!Raid” message appears on all
output monitors, and another message appears when the operator shuts
down the application, to invite him to replace the disk and rebuild the
RAID array.
Refer to the XT Tech Ref Hardware manual for details on the RAID
system and its maintenance.
N
ETWORK
E
RROR
M
SG
Possible values: Yes (default) / No
This function displays an error message (!Net) on the output monitor when the
network connection is faulty and another message (ÆNet) when the network
becomes available again and the system is trying to re-connect.
K
EYWORD
I
NFO
Possible values: No (default) / Yes
Up to 3 keywords and a ranking can be assigned to every clip. When the Keyword
Info parameter is set to “Yes”, these keywords and ranking appears on the OSD of
the output monitors when the clip is loaded on its Short IN point. As soon as the
operator starts jogging into the clip or initiates a playback, this information is
removed from the OSD so that the video content is clearly visible.
A
UDIO
M
ETERS ON
OSD
Possible values: Yes (default) / No
This parameter enables/disables the display of audio meters at the bottom of each
output monitor.
A
UDIO
M
ETERS
A
DJ
. (
D
B)
Possible range: -83.2dB to 0dB. Default: 0dB
This parameter allows adjusting the sensitivity of audio meters on the OSD of the
output monitors. A positive value means that the meters will be more sensitive.
2.2.4 N
ETWORK
S
ETTINGS
You can also define the Clip edit by network setting on page 3.1, F6 of the setup
menu on the Remote Panel. You will find a description of these settings in the
Multicam user manual.
