EVS XSense Version 10.04 - January 2011 Configuration Manual - Manual (Page 45)

Issue
10.04.B XSense – Version 10.04 – Configuration Manual
EVS Broadcast Equipment – January 2011
36
Setting Name Description
Clear PL Allows clearing the specified playlist. You can choose to
delete only the EDL only or the EDL and the clips. Select the
values and press ENTER to execute.
CLEAR UNUSED
EDITREC CLIPS Deletes all unused EditRec clips on the local server. A
confirmation is requested.
Close Edit Finalizes the editing and closes the loaded playlist. As long
as the edit is not closed, the EditRec playlist is a 24-hour
block of video and/or black material. Once the edit is closed,
the black material is cut out of the playlist, which is thus
restricted to the recorded clips.
Important:
It is recommended to close the edit when you stop
working with EditRec as the EditRec playlist is not
automatically closed when the Multicam application
is closed.
EE Activates the E to E
Stop Behavior Defines the channel behavior when it is in stop mode:
• Black screen (PB)
• EE
Clip Name Name to be automatically assigned to the edits of an EditRec
playlist. It is made up of 8 user-defined characters followed
by the LSM ID, automatically assigned by the Server.
Clip VarID VarID to be automatically assigned to the edits of an EditRec
playlist. It is made up of 24 user-defined characters followed
by the UmID, automatically assigned by the Server.
A
UDIO
S
ETTINGS
Setting Name Description
Edit Audio Fade Audio effect to be applied to the clip boundaries and included
in the clip material.
Edit: Undo Cancels the last EditRec action. You can undo the last 9
actions.
