Issue
10.04.B XSense – Version 10.04 – Configuration Manual
EVS Broadcast Equipment – January 2011
2
2. Setup in Multicam
2.1 INTRODUCTION
2.1.1 O
VERVIEW
When you work in Spotbox mode, the ‘Setup Configuration’ module available in the
Multicam application, using the SHIFT-F2 keyboard combination, allows you to
configure the Multicam software and define server settings in relation to
timecodes, protocol communication, etc.
The other Multicam modules are discussed in the following manuals:
• Monitoring modules in the XT Tech Ref Software manual
• Multicam application in the User manual
This module contains several pages, i.e. windows, which are described in details
in this section:
Setup page and section
name Content
Page 1
See Section 2.2 ‘General
Settings (Page 1)’, on page
3.
It includes several general settings on the
timecodes, the OSD, the VGA, the network, the
clip management, the record trains, the channel
names, the RS422 protocols.
Page 2
See Section 2.3 ‘VITC/ANC
Timecode Management (Page
2)’ on page 12.
It includes detailed settings on the insertion of
VITC or ANC timecodes, channel by channel.
Page 3
See section 2.4 ‘SDTI
Network Priorities (Page 3)’,
on page 16 and 2.5 ‘SMPTE
334M Packets Management
(Page 3)’, on page 16. It includes settings on:
• the priorities on the SDTI network
• the SMPTE 334M packet management
Page 4
See section 2.6 ‘GPI Settings
(Page 4), on page 19.
It includes the settings on the GPIs IN and OUT
Page 5
See section 2.7 ‘RS422
Protocol Settings (Page 5)’,
on page 24.
It includes settings on the VarID used with the
VDCP protocol.
