16 controller and protocol settings, 1 rs422 #1, 2 rs422 #2 – EVS XSense Version 10.04 - January 2011 Configuration Manual User Manual
Page 79: 3 rs422 #3, 4 rs422 #4, Ttings, 1 rs422, 2 rs422, 3 rs422, 4 rs422
Issue
10.04.B
XSense – Version 10.04 – Configuration Manual
EVS Broadcast Equipment – January 2011
70
3.16 CONTROLLER AND PROTOCOL
SETTINGS
Port Device/Protocol p.7.1
RS422 #1 EVS Remote [F7]ID Type:
[F2]RS422 #2 EVS Remote ID LSM
[F3]RS422 #3 EVS Remote
[F4]RS422 #4 Sony BVW75
[F5]RS422 #5 Sony BVW75
[F6]RS422 #6 Touch Screen
[Menu]Quit [Clr+F_]Dft [F9]PgUp [F0]PgDn
This page is used to define what type of device/controller is connected to each
RS422 port of the server.
3.16.1 RS422
#1
Value: EVS Remote
When working with an XSense configuration, the first RS422 port must always be
connected to an EVS Remote. No other possible selection.
3.16.2 RS422
#2
Possible values: EVS Remote, Sony BVW75, XtenDD35, Odetics, VDCP, EVS
AVSP, EVS IPDP, Edit Rec, ---------
Default: EVS Remote
3.16.3 RS422
#3
Possible values: EVS Remote, Sony BVW75, XtenDD35, Odetics, VDCP, EVS
AVSP, EVS IPDP, Edit Rec, ---------
Default: EVS Remote
3.16.4 RS422
#4
Possible values: EVS Remote, Sony BVW75, XtenDD35, Odetics, VDCP, EVS
AVSP, EVS IPDP, Edit Rec, ---------
Default: Sony BVW75
