10.04.B XSense – Version 10.04 – Configuration Manual
EVS Broadcast Equipment – January 2011
34
2.11.3 S
ETTINGS
This section describes the settings that need to or can be defined with the EditRec
protocol.
C
HANGING
S
ETTINGS
You can only edit the settings when the EditRec player channel is stopped.
When you leave a field followed by [ENTER], you need to select ENTER and press
the ENTER key on the keyboard to apply the changes.
T
IMECODE
S
ETTINGS
These are the TC settings of the playlist loaded on the EditRec channels.
Setting Name Description
Start TC Timecode to be used for the first frame of the playlist. This
can be changed even after a playlist has been created. Press
ENTER to apply.
DF / NDF Specifies whether timecode is drop frame or non drop frame.
Preroll TC Duration of the playlist preroll in seconds.
Edit TC – Serial
Sony LTC
Type of timecode used in communications between the Sony
controller and the EditRec engine when the controller works
with the LTC.
This field is not editable. The value is always ‘Edit TC’,
which means the timecode of the playlist based on the Start
TC.
Edit TC – Serial
Sony VITC Type of timecode used in communications between the Sony
controller and the EditRec engine when the controller works
with the VITC.
Possible values:
• Edit TC: playlist timecode based on the Start TC defined.
• User TC: clip timecode from the USER TC table.
Insert TC to SDI Timecode inserted in the VITC in SD or in the HANC in HD
when the playlist is played out on the EditRec player
channel.
Possible values:
• Edit TC: playlist timecode based on the Start TC defined.
• Default: timecode selected in the D-VITC field in SD, or in
the HANC VITC / LTC fields in HD defined on page 2 of the
Setup Configuration.
User TC of
created clips Specifies the TC type inserted into User TC for the created
Clips.
