XSense – Version 10.04 – Configuration Manual
EVS Broadcast Equipment – January 2011
Issue
10.04.B
67
3.14 MAPPING NETWORK CAM
Mapping network cam p.6.3
[F1]Authorize cam mapping : Yes
Cam A
: Local
Cam B : Local
[F3]Cam C : CamA/01
[F4]Cam D : CamB/01
[Menu]Quit [Clr+F_]Dft [F9]PgUp [F0]PgDn
This is a software option. It allows users to map network cameras to unused
camera position on the Remote up to the D camera. For instance, if the
configuration is 2IN 2OUT, it is possible to map 2 network cameras.
The mapping allows a quick selection of network trains on the network. Those
cameras are NOT recorded on the local server, they remain recorded on the
destination server.
The F1 key allows the user to enable or disable the option.
The other F_ keys allow the user to perform the mapping:
• If the camera is local (cam A and B on the example), no F_ key is assigned to
it.
• If the position is free and can be used by a network camera, the F_ key is
available: The F2 to F4 keys can be assigned to respectively Cam B, C or D in
this case depending on the configuration defined in the Setup.
To map a distant camera to a local camera position, select the cam position with
the corresponding F_ key and jog with the dial to reach the desired network
camera to map.
