10.04.B XSense – Version 10.04 – Configuration Manual
EVS Broadcast Equipment – January 2011
78
3.19.4 GPI
S
OUT D
EFINITION
GPI OUT Settings p.8.3
GPI# Function Type
1 [F1]----------- [F5]----------
2 [F2]----------- [F6]----------
3 [F3]----------- [F7]----------
4 [F4]----------- [F8]----------
[Menu]Quit [Clr+F_]Dft [F9]PgUp [F0]PgDn
The GPIs OUT have been implemented primarily for the Replace function. On the
IN/OUT point when executing the Replace, users can trigger GPIs OUT.
For each GPI input, the operator has the possibility to define the following
parameters:
• The function that will trigger a GPI OUT: (Empty) not used (default value) or
Replace
• The type of GPI signal that will be used. Possible values are:
o
Open-Low
o
Open-Low Pulse
o
Close-High
o
Close-High Pulse
Example
Users can select all types of GPIs. The behavior varies accordingly:
Before the
IN
On
Replace IN Between IN
and OUT On
Replace
OUT After the
OUT
Close-
High Low High High Low Low
Open-
Low High Low Low High High
Close-
High
Pulse
Low High Pulse Low High Pulse Low
Open-
Low
Pulse High Low Pulse High Low Pulse High
