XSense – Version 10.04 – Configuration Manual

EVS Broadcast Equipment – January 2011

Issue

10.04.B

Value Meaning

file

name

of the system. Keyword files can be imported using the
Import/Export Setup Files function of the Maintenance menu of the
EVS Menu (refer to the XT Tech Ref Software manual for details).
The F8 key allows the operator to delete the selected file
(confirmation required). Details about the keywords file format and

keywords-related functions are available in the ‘Keyword
Management’ section in the Multicam operational manual.

3.9.8 K

EYWORD

ODE

Possible values: List (default), Numeric
This parameter specifies the keyword assignment/search mode on the EVS Remote
Panel:

•

List: It will display the keywords by groups of 8 on the LCD of the Remote

Panel and the operator can select them with the corresponding F_ key.

•

Numeric: It doesn’t display the keywords list on the LCD, but allows the

operator to enter directly the keyword ID using the F_ keys. The Numeric mode
is faster when the operator knows the position of the keywords inside the
keywords file, either from memory, using the VGA keyword screens, or using a
print of the keywords list.

Clips (PUSH)

p.3.3

[F1] Target : SDTI+Gigabit
[F2] Target 1 : Yellow 255.255.255.255
[F3] Target 2 : Brown #04
[F4] Mode : Short
[F5] Receive Pg : 1 2 3 4 5 6 7 8 9 0

[Menu]Quit [Ctr+F]Dft [F9]PgUp [F0]PgDn

3.9.9 T

ARGET

Possible values: SDTI (default), Gigabit, SDTI+Gigabit

This parameter specifies which EVS servers will be listed as possible targets for
push actions when the user selects:

•

the default Target 1 and Target 2 in the settings, or

•

a target for a specific push action if no default target has been configured.

SDTI:

Only SDTI targets will be listed. The servers are listed by
their network system name and number.

Gigabit:

Only EVS servers reachable via the GigE network and not
present on the same SDTI network will be listed. The servers
are listed by their GigE server name, and IP Address.
