XSense – Version 10.04 – Configuration Manual
EVS Broadcast Equipment – January 2011
Issue
10.04.B
73
3.17.3 S
ECONDARY
C
ONTROLLER FOR
PGM1/2/3/4
Possible values: list of protocols defined on page 7.1. Default: ---------- --
Available only if the main controller for that channel is an EVS remote.
Special Control Settings p.7.3
Main RS422 Second. RS422
PGM5:[F1]---------- -- [F5]---------- --
[Menu]Quit [Clr+F_]Dft [F9]PgUp [F0]PgDn
Multicam is capable of operating in XSense mode with 5 play channels assigned.
On this Protocol assignment page, the user can define the protocols and ports to
manage this channel.
The XSense Remote by itself cannot control PGM5.
3.17.4 C
ONTROL
T
YPE
Special Control Settings p.7.4
Control type OSD Display
PGM1:[F1]Parallel [F5] Main
PGM2:[F2]Exclusive
PGM3:[F3]Exclusive
PGM4:[F4]Exclusive
[Menu]Quit [Clr+F_]Dft [F9]PgUp [F0]PgDn
Possible Values: Parallel, Exclusive (default)
This setting allows channels to either be controlled in ‘Exclusive’ control (same as
allowed in the past with 2 n d Control Mode) or in Parallel Mode.
In Parallel mode, the user can define which device will manage the OSD display
characters (i.e. the main or the secondary controller).
Limitations
Some configurations (*) lead to the following message to warn the users of the
limitations of the selected configuration:
“Warning: your parallel selection is not fully operational”
