Issue
10.04.B XSense – Version 10.04 – Configuration Manual
EVS Broadcast Equipment – January 2011
68
3.15 HYPERMOTION CONFIGURATION
Hypermotion Configuration p.6.4
[F1]Hypermotion : Yes
[F2]Recorder : CAM A
[F3]Remote Mode : Hypermotion Only
[F4]Port : Lan PC
[F5]IP address : 127.0.0.1
[F6]Dial Speed : 010 X
[Menu]Quit [Clr+F_]Dft [F9]PgUp [F0]PgDn
The Hypermotion feature is a software option (license code 20) that allows
controlling a hypermotion camera from the Remote Panel. The supported
hypermotion cameras are Photron, Vision Research and ARRI cameras.
3.15.1 H
YPERMOTION
Possible values: No (default), Yes
When this parameter is set to ‘Yes’, the Hypermotion feature is active: Users can
access and use the Hypermotion menu on the Remote Panel via the SHIFT+D key
combination.
When this parameter is set to ‘No’, the Hypermotion feature is not active: The
Hypermotion menu can be accessed but not used on the Remote Panel.
3.15.2 R
ECORDER
Possible values: CAM A to CAM D. Default: last CAM
This parameter specifies the recorder channel to which the A/V material from the
hypermotion camera will be sent. The default value is the last CAM defined in the
channel configuration, for example CAM C in 3 IN 3 OUT configurations.
3.15.3 R
EMOTE
M
ODE
Possible values: Hypermotion only (default), Hypermotion + LSM
The parameter specifies what the server will control:
• Hypermotion only: The server controls only the hypermotion camera.
When this value is selected, an additional Remote is made available in the
main menu of the Remote Panel, since the hypermotion camera is considered
as an additional external camera.
• Hypermotion + LSM: The server controls the hypermotion camera and one
PGM in exclusive mode.
For more information on the assignment of the PGMs and the hypermotion camera
to the Remotes, refer to the section related to the Hypermotion Management in the
XT Tech Ref Software manual.
