XSense – Version 10.04 – Configuration Manual
EVS Broadcast Equipment – January 2011
Issue
10.04.B
79
3.19.5 GPI
S
OUT
A
DVANCE AND
D
URATION
GPI OUT Settings p.8.6
GPI# Advance Duration
1 [F1]Disable [F5]01s00fr
2 [F2]Disable [F6]01s00fr
3 [F3]Disable [F7]01s00fr
4 [F4]Disable [F8]01s00fr
[Menu]Quit [Clr+F_]Dft [F9]PgUp [F0]PgDn
GPI OUT Settings p.8.7
GPI# Advance Duration
5 [F1]Disable [F5]01s00fr
6 [F2]Disable [F6]01s00fr
7 [F3]Disable [F7]01s00fr
8 [F4]Disable [F8]01s00fr
[Menu]Quit [Clr+F_]Dft [F9]PgUp [F0]PgDn
GPI OUT Advance
Possible values: Disable (default) / 00s01fr to 02s00fr
Possible values: up to 2 seconds, frame by frame (like GPI delay)
When a GPI out advance setting is set (for instance 2 fr.), the GPI OUT is sent 2
frames in advance.
GPI Pulse Duration
Possible values: Disable / 00s01fr to 02s00fr. Default: 01s00fr.
Set the default duration for pulse GPIs.
