Selected and current altitudes can also be displayed in meters (readouts displayed above the normal readouts
in feet; Figure 2-10). Note that the altitude tape does not change scale.
Displaying altitude in meters:
1)
Select the PFD Softkey to display the second-level softkeys.
2)
Select the ALT UNIT Softkey.
3)
Select the METERS Softkey to turn on metric altitude readouts.
4)
Select the BACK Softkey to return to the top-level softkeys.
A magenta Altitude Trend Vector extends up or down the left of the altitude tape, the end resting at the
approximate altitude to be reached in 6 seconds at the current vertical speed. The trend vector is not shown if
altitude remains constant or if data needed for calculation is not available due to a system failure.
The barometric pressure setting is displayed below the Altimeter in inches of mercury (in Hg) or hectopascals
(hPa) when metric units are selected. Adjusting the altimeter barometric setting creates discontinuities in VNV
vertical deviation, moving the descent path. For large adjustments, it may take several minutes for the aircraft
to re-establish on the descent path. If the change is made while nearing a waypoint with a VNV Target Altitude,
the aircraft may not re-establish on the descent path in time to meet the vertical constraint.
Selecting the altimeter barometric pressure setting:
Turn the BARO Knob to select the desired setting.
Selecting standard barometric pressure (29.92 in Hg):
Press the BARO Knob to select standard pressure.
Or
:
1)
Select the PFD Softkey to display the second-level softkeys.
2)
Select the STD BARO Softkey.
Changing altimeter barometric pressure setting units:
1)
Select the PFD Softkey to display the second-level softkeys.
2)
Select the ALT UNIT Softkey.
3)
Select the IN Softkey to display the barometric pressure setting in inches of mercury (in Hg).
Or, Select the HPA Softkey to display the barometric pressure setting in hectopascals.
4)
Select the BACK Softkey to return to the top-level softkeys.
