190-00763-01 Rev. A Garmin G1000 Pilot’s Guide for the Piper PA-46 Meridian 11
SYSTEM OVERVIEW
SY
STEM
O
VER
VIEW
FLIGHT
INSTRUMENTS
EICAS
AUDIO P
ANEL
& CNS
FLIGHT
MANA
GEMENT
HAZARD
AV
OID
ANCE
AFCS
ADDITIONAL
FEA
TURES
APPENDICES
INDEX
4 PROC Key Gives access to IFR departure procedures (DPs), arrival procedures (STARs), and
approach procedures (IAPs) for a flight plan or selected airport
5 Joystick Turn to change map range
Press to activate Map Pointer for map panning
6 Alphanumeric Keys Allow data entry (rather than using the FMS Knob to select characters/numbers)
7 BKSP Key Moves cursor back one character space and removes last character entered
8 SPC Key Adds a space character
9 ENT Key Validates or confirms a menu selection or data entry
10 CLR Key Erases information, cancels entries, or removes menus
Press and hold to display the MFD Navigation Map Page (MFD only).
11 SEL Key Arrows move light blue Softkey Selection Box (Figure 1-10) on selected display
Press the center to activate the selected softkey
12 Decimal Key Enters a decimal point character
13 Plus-Minus (±) Key Toggles entry between the + and - characters
14 NAV Key Selects/deselects NAV radio tuning mode on the MFD/PFD Control Unit
15 COM Key Selects/deselects COM radio tuning mode on the MFD/PFD Control Unit
16 Frequency Transfer
Key
(EMERG) Transfers between active and standby selected COM or NAV tuning frequencies
Press and hold 2 seconds to tune the emergency frequency (121.5 MHz) automatically
into the active frequency field
17 PFD Key When selected, the MFD/PFD Control Unit can be used to access PFD functions
18 MFD Key When selected, the MFD/PFD Control Unit can be used to access MFD functions
(default display control mode)
19 FMS/NAV-COM
Knob NAV/COM Tuning Modes: Acts as the NAV or COM Knob
PFD/MFD Control Modes: Acts as the FMS Knob
