Garmin G1000 Pilot’s Guide for the Piper PA-46 Meridian 190-00763-01 Rev. A 348
HAZARD AVOIDANCE
SY
STEM
O
VER
VIEW
FLIGHT
INSTRUMENTS
EICAS
AUDIO P
ANEL
& CNS
FLIGHT
MANA
GEMENT
HAZARD
AV
OID
ANCE
AFCS
ADDITIONAL FEA
TURES
APPENDICES
INDEX
6.4 TERRAIN-SVS
WARNING: Do not use TERRAIN-SVS information for primary terrain avoidance. TERRAIN-SVS is intended
only to enhance situational awareness.
NOTE: Terrain data is not displayed when the aircraft latitude is greater than 75° North or 60° South.
NOTE: The TAWS option will take precedence over TERRAIN-SVS.
TERRAIN-SVS is a terrain awareness system available with the Synthetic Vision System (SVS). SVS functionality
is offered as an optional enhancement. Optional Terrain Awareness and Warning System (TAWS) or standard
TERRAIN-SVS is integrated within SVS to provide visual and auditory alerts to indicate the presence of threatening
terrain relevant to the projected flight path. For detailed information regarding SVS, refer to the Synthetic Vision
System (SVS) section of the G1000 Pilot’s Guide.
TERRAIN-SVS does not comply with TSO-C151b certification standards. It increases situational awareness
and aids in reducing controlled flight into terrain (CFIT). Do not confuse TERRAIN-SVS with Terrain Awareness
and Warning System (TAWS). TAWS is more sophisticated and robust, and it is TSO-C151b certified. Although
the terrain and obstacle color map displays are the same, TAWS uses more sophisticated algorithms to assess
aircraft distance from terrain and obstacles.
TERRAIN-SVS does not provide the following:
• Premature Descent Alerting (PDA)
• Excessive Descent Rate (EDR)
• Negative Climb Rate (NCR)
• Descent to 500 Feet Callout (DFC)
TERRAIN-SVS requires the following components to operate properly:
• Valid 3-D GPS position
• Valid terrain/obstacle database
TERRAIN-SVS displays altitudes of terrain and obstructions relative to the aircraft position and altitude with
reference to a database that may contain inaccuracies. Terrain and obstructions are shown only if they are in the
database. Terrain and obstacle information should be used as an aid to situational awareness. They should never
be used to navigate or maneuver around terrain.
Note that all obstructions may not be available in the terrain and obstacle database. No terrain and obstacle
information is shown without a valid 3-D GPS position.
The GPS receiver provides the horizontal position and altitude. GPS altitude is derived from satellite position.
GPS altitude is then converted to a mean sea level (MSL)-based altitude (GPS-MSL altitude) and is used to
determine terrain and obstacle proximity. GPS-MSL altitude accuracy is affected by satellite geometry, but is not
subject to variations in pressure and temperature that normally affect pressure altitude sensors. GPS-MSL altitude
does not require local altimeter settings to determine MSL altitude. It is a widely-used MSL altitude source.
Terrain and obstacle databases are referenced to MSL. Using the GPS position and altitude, the TERRAIN-SVS
feature portrays a 3-D picture of the surrounding terrain and obstacles relative to the position and altitude of the
